Add-in with C#

To create a VBE add-in for Excel using C# you can use Visual Studio 2022.
Create a COM Add-in that implements the IDTExtensibility2 interface.
Project Name - VBACOMAddin
Add two additional references.
(1) Assemblies, Extensions: Microsoft.Vbe.Interop
(2) References, Add Reference, COM, Add "Microsoft Visual Basic for Applications Extensibility 5.3" (VBIDE)
Replace the 2 GUID Ids (
Add the following code changes to the MyConnect.cs file

public class MyConnect : IMyConnect
   private Microsoft.Vbe.Interop.VBE _VBEObject;


namespace VBACOMAddin1
    public class MyConnect
        public Microsoft.Vbe.Interop.VBE _ApplicationObject;
        public Microsoft.Office.Core.COMAddIn _AddinInstance;

        public void OnConnection(
            object Application,
            Extensibility.ext_ConnectMode ConnectMode,
            object AddInInst,
            ref System.Array custom)
            this._ApplicationObject = (Microsoft.Vbe.Interop.VBE)Application;

            if (this._AddinInstance == null)
                this._AddinInstance = (Microsoft.Office.Core.COMAddIn)AddInInst;
                this._AddinInstance.Object = this;

            switch (ConnectMode)
                case Extensibility.ext_ConnectMode.ext_cm_Startup:
                    // normal execution path - don't initialize just yet, wait for OnStartupComplete to be called by the host.
                case Extensibility.ext_ConnectMode.ext_cm_AfterStartup:
        public void OnDisconnection(
            Extensibility.ext_DisconnectMode RemoveMode,
            ref System.Array custom)
            this._ApplicationObject = null;
            this._AddinInstance = null;
        public void OnAddInsUpdate(ref System.Array custom)
        { }
        public void OnStartupComplete(ref System.Array custom)
        public void OnBeginShutdown(ref System.Array custom)
        { }

        public void InitializeAddIn()
                this._AddinInstance.ProgId + " loaded in VBA editor version " +

Make sure the Guid Id is replaced using (Tools > Create GUID).
Select Build > Build Solution).
At this point no registry entries are added to the registry.
Select (Project > Properties).
Display the Build tab.
Tick the "Register for COM Interop" checkbox (requires admin rights).
Close the Properties window.
Select (Build > Build Solution).
When the solution is built a "TLB" file appears in the "\bin\Debug\" folder.
When the solution is built the RegAsm tool automatically runs.
The RegAsm tool adds the necessary class and interface information to the registry.

C:\Windows\Microsoft.NET\Framework\v4.0.30319\ RegAsm /codebase VBACOMAddin.dll

Registry Entry

Create the following registry entry

(String)(Default) - (value not set)
(String) Description - VBA COM Addin
(String) FriendlyName - VBACOMAddin
(DWord) LoadBehavior - 3

Registry Keys - COM Add-in

Microsoft Office COM add-ins are identified by reading from the registry.
You can view the registry by going to the Windows start menu, choosing Run, typing regedit and pressing OK.
There must be a key representing the COM Add-in under the Addins key:
64 Bit Office - HKEY_CURRENT_USER\Software\Microsoft\VBA\VBE\7.1\Addins64\
32 Bit Office - HKEY_CURRENT_USER\Software\Microsoft\VBA\VBE\7.1\Addins\

(String)(Default) - (value not set)
(String) Description - A Long Description
(String) FriendlyName - VBACOMAddin
(DWord) LoadBehavior - 0

Description - A brief description of the add-in.
FriendlyName - A user friendly name that is displayed in the COM add-ins dialog box.
Load Behavior - The load behaviour of the add-in.
